Freedom SULCO

Sulco, 3-piece hydrophobic IOL (3HPC360) with PVDF haptics is the newest addition to the family of Freedom Premium IOLs, making Freedom the first Indian manufacturer to do so and compete with the world leaders in IOL market.

Or please call FAISAL: 079 242 2817 or AHMED: 082 414 1472

Description

The Optics & All about the Haptics
Freedom Sulco is a UV light-absorbing posterior chamber hydrophobic acrylic lens designed to be implanted in the capsular bag following extra capsular cataract extraction. The opticis biconvex design with 6mm Aspheric design as well as spherical optics, with 360° Square Edge to reduce PCO, and 13mm overall size.

Polyvinylidene fluoride monofilament haptics, PVDF have better shape recovery and loop memory compared to other haptic materials. Very malleable and resistant, PVDF haptics are designed for better capsular bag stability and to eliminate capsular bag stretching. PVDF haptics create a better flange than PMMA haptics, and can prevent conjuctival erosion during intra scleral haptic fixation.

Cap C haptics design with 5° angulation are best suited to the capsular bag for long term optimal centration, refractive stability and minimal zonular stress

Original IOL Power Adjustment to IOL Power for Sulcus Placement
0.0 to 8.5 None
9.0 to 17.5 -0.5D
18.0 to 26.5 -1.0D
27.0 and higher -1.5D



FREEDOM SULCO JET with 2.6MM Cartridge Size

Freedom SULCO can be delivered through an incision as small as 2.6 mm with Freedom SULCO JET implantation system. It is a Reusable Titanium Injector, designed specifically for Freedom SULCO and Freedom Cartridge. Freedom recommends using equivalent appropriate equalified insertion instrument or system to insert FREEDOM SULCO 3-PIECE.




Model 3HPC630
Optic Design Biconvex - 360° Square Edge with Aspheric Optic
Material Hydrophobic Acrylic
Optic Size 6.00 mm
Over All length 13.00 mm
Haptic Angle
Estimated A-Constant A Constant : 118.0 | Hoffer Q : 4.97 | Holladay : 1.223



Haigis : a0=1.277/a1=0.400/a2=0.100

Recommended
Optical A-Constant
A Constant SRK/T : 118.40 | A Constant SRK/II : 118.70



Hoffer Q : 5.14 | Holladay 1 : 1.35 | Haigis : a0=0.912/a1=0.400/a2=0.100

Diopter Range 6.00 D to 30.00 D (0.5 Diopter increments)
Cartridge Size 2.60 mm
Sterilization Ethylene Oxide
