Suoer SW-21 Ultrasound

Click here to view the pdf brochure

The SW-21 DELTA Ultrasound Scanner by SUOER, is a modular, upgradable and portable ultrasound scanner, here to set new standards in ultrasound biometry market, worldwide. Through its premium specifications, the device offers high quality and clear ultrasound images and allows the user to take both images and videos of the measurement. The device can be selected between any combination of A/B/P/UBM Scan and additional scanning modes can be added later on.

Features

• Modular ophthalmic ultrasound platform, allowing probes to be mixed and matched to meet different needs
• Easy-to-use workstation software, friendly user interface
• Industry-leading image quality and measurement accuracy
• Support DICOM 3.0

Probe’s Characteristics

B Scan

• Frequency: 10MHz, Magnetic driven, noiseless
• Scanning Mode: Sector Scanning
• Magnify: Multi continuous magnification, Real-Time magnification
• Resolution: Lateral ≤0.3mm, Vertical≤0.2mm
• Geometry Position Precision: ≤5%, Vertical≤3%
• Depth: 60mm
• Enhance the part of vitreous body retinal
• Gain of Probe: 30dB-105dB
• Scanning Angle: 53⁰
• Gray Scale: 256
• False Color: Multi Colors
• Measurement Type: Multigroup distances, perimeters and areas
• Image Post processing: Multiple curves processing, Pseudo-color processing curve
• Movies: 100 image movie, AVI JPG format image output

A Scan

• Frequency: 10MHz, with LED
• Depth: 40mm
• Precision: ±0.05mm
• Measurement: Anterior chamber depth, lens thickness, vitreous body length, total length and average
• Eye Mode: Phakic/Aphakic/Dence/Various IOL
• IOL Formula: SRK-II, SRK-T, HOFFER-Q, HOLLADAY, BINKHORST-II, HAIGIS
• Stat. Calculation: Average and standard deviation
• Store: 10 Scanning results for each eye

Full Scale UBM

• Frequency: 50MHz
• Scanning Mode: Wide Range Sector, Scanning Mode, Undistorted, Sulcus-to sulcus
• Scanning Range: 16mm*9mm; 10*6.5mm
• Vertical Precision: ≤40μm
• Lateral Precision: ≤40μm
• Scanning Lines: 1024 Lines, 15μm between each lines
• Geometry Location Precision: Vertical ≤3%, Lateral ≤3%, Non data interpolation, none distortion Imaging.
• Display Mode: UBM,UBM+A
• System Performance: It have a special independent 50μm ultrasonic amplification system make the anterior segment image clearer
• Windows Platform: Windows System

Others

• Display Mode: B,B+B,B+A,A
• Hint: Preset keyword
• Case Search: Multi-keywords
• Working Platform: Windows System
• User Defined report template
