Inami L-4550

Prism Compensater

 Click here to view the pdf catalogue

Determination of sphere power.

Range of measurement of vertex power:0 to +- 25.00D.
Up to +- 3.00D. in 0.125D. steps and over 3.00D. in 0.25D. steps.

Determination of cylinder power.

• Determination of cylinder axis: 0 degrees to 180 degrees in 1 step.
• Determination of prism power: 6 (read in view field).

Prism compensator: Maximum 15 in 1 step.

• Instrument tilting angle: Freely adjustable between 30 to 90 .
• Measurable lens diameter: 32mm to 90mm.
• Accurate centering and marking of lenses.
• Lamp: 110V, 220V, 240V-15W.(L4530V0)
• Size: 413mm(H:at 90 degrees )335mm(H:at 30 ) 160mm(W) 422(D)mm.
• Weight: 4.9kg.

Accessories:

2 spare lamps, a fuse and a dust cover.
Optional Accessories: Prism Compensator.

SPECIFICATIONS

Complete analysis of lenses.

A. Determination of sphere power.
Range of measurement of vertex power: 0 to 25.00D.
Up to 3.00D. in 0.125D. steps and over 3.00D. in 0.25D. steps.
B. Determination of cylinder power.
C. Determination of cylinder axis: 0 to 180 in 1 step.
D. Determination of prism power: 6.
Prism compensator: Maximum 15 in 1 step.2.

Instrument tilting angle:

• Freely adjustable between 30 to 90 .
• Measurable lens diameter: 32mm to 90mm.
• Accurate centering and marking of lenses.
• Lamp: 110V, 220V, 240V-15W.(L4530V0)
• Size: 413mm(H:at 90 )335mm(H:at 30 ) 160mm(W) 422(D)mm.
• Weight: 4.9kg.
• Accessories: 2 spare lamps, a fuse and a dust cover.
• Optional Accessories: Prism Compensator.
