Freedom TRIFLEX

The advanced Trifocal Hydrophobic Intraocular Lens of Freedom is designed to provide intraocular lens, providing CLEAR VISION for NEAR, INTERMEDIATE and FAR distance. Now our patients can enjoy an independent active lifestyle, free of spectacles or other visual aids.

Or please call FAISAL: 079 242 2817 or AHMED: 082 414 1472

Description

Unique manufacturing process

Enhanced Optical design of Freedom hydrophobic material with low refractive index over hydrophilic material ; with round edge zones provides better results against photopic conditions by reducing internal reflection and glares. 360° square edge with thicker haptic design provides dual barrier technology against lower risk of PCO formation with excellent rotational stability. The aspheric design technology combined with a ABBE number of 50 allows for a negative spherical aberration of 0.15µm to offset the positive sphericity of human cornea for improved contrast sensitivity.

Freedom TRIFLEX features :

  • The central zone is of 4.50 mm diameter, has 16 diffractive zones. The remaining 1.50mm portion of the lens has the refractive zone.
  • Addition +1.85D (Intermediate) & 3.5D (Near)
  • Diopter Range from +5.00 D to +30.0 D with 0.50 D step
  • UV Filter (Energy cut below 500nm)
  • Maximum Light Transmission under any Light Conditions
  • Increased Bio-mechanical Stability
  • Excellent Far, Intermediate & Near Vision RNI-Distribution for Far, Intermediate & Near 40/25/35
  • Free of Glistening & Whitening



Model TRPC602SQ TRPC602SQY
Optic Design Single Piece, Diffractive-Refractive, Trifocal, 360° Square Edge with Aspheric Optic
Material Hydrophobic Acrylic Yellow Hydrophobic Acrylic
Addition Near Addition : +3.5D / Intermediate addition : +1.85D
Optic Size 6.00mm
Over All length 13.00mm
Haptic Angle 0°, Modified C
Estimated A-Constant A Constant : 118.4  -  Hoffer Q : 5.20  -  Holladay 1 : 1.87  -  Haigis : a0=1.527/a1=0.400/a2=0.100
Recommended Optical A-Constant A Constant SRK/T : 119.20  -  A Constant SRK/II : 119.50



Hoffer Q : 5.65  -  Holladay : 1.87  -  Haigis : a0=1.441/a1=0.400/a2=0.100

Refractive Index 1.49
Sterilization EO
Incision 2.20 - Available in Preloaded system also
