Suoer Keratometer SW-100

Features :
1.It can observe the eye directly through the screen.
2.Very light, only 0.5kg with batteries

Specifications :
1.Measuring range : 6.5mm-9.5mm ( curvature radius )
2.Precision: ±0.05mm
3.Resolution of curvature radius of cornea: 0.01mm
4.Resolution of axial angle of cornea: 1 Deg
5.Output: wireless infrared thermal printer
6.Singel measuring time:0.03s
6.Power:50mW+15%
7.Power Supply : three AA batteries
8.Net Weight: 0.5kg(with batteries), Machine Demension : 240mm x 90mm x 60mm
9.Packing details : Gross Weight : 2kg, 30cm x 16cm x 10cm

Click here to view the pdf catalogue

Click here to view the Simple Manual for Measurement

Demo Video:

Method 1:

Method 2:
